Sometimes simple algorithms are just wrong. In this case shuffling an array looks like a foolproof task, but the obvious doesn't always work and the correct algorithm is just a tiny change away. Find out about why it doesn't work and the correct way to shuffle.
Probability and randomness is something we all understand but also something we tend to make big mistakes in using.
For example, consider the following very reasonable looking shuffle algorithm (in C#):
for (int i = 0; i < data.Length; i++) { swap(ref data[i], ref data[R.Next(data.Length)]); }
where R.Next(M) returns a random integer in the range 0 to M1 and swap is:
void swap(ref int a, ref int b) { int t = a; a = b; b = t; }
You can see the idea is to scan through the entire array and swap each element with a random element anywhere in the array.
If you want to explain this to a nonprogrammer simply explain that the shuffle works by picking up a deck of cards, taking the first card and swapping it in the deck with a randomly chosen card and repeating this action on the second, third and subsequent cards until you reach the end of the deck.
This is obviously a good shuffle since each card has been move to a random location  it's a perfect shuffle  or is it?
The result has to be a shuffled array and this means that getting any particular sequence is random, i.e. all possible sequences are equally likely.
Notice that there are a number of flaws in this algorithm. The first is that any given element may be moved more than once  and so you can say that it overdoes the task of shuffling.
But this can't be anything more than an efficiency issue can it?
In fact this over shuffling is very much the cause of a much more important problem. The shuffled data or deck of cards isn't in random order in the sense that some sequences are more likely than others.
To see that this is the case consider the simplest interesting case  three elements:
A B C
The first iteration swaps A with another element at random, i.e. either A, B or C, so the three equally likely configurations after the first iteration are:
no change A B C swap with B B A C swap with C C B A
The second iteration starts with one of the three arrangements generated at the first iteration and the swaps are:
Second position with first position gives one of:
A B C > B A C B A C > A B C C B A > B C A
Second position with second position gives one of:
A B C > A B C B A C > B A C C B A > C B A
and finally second position with third position gives one of:
A B C > A C B B A C > B C A C B A > C A B
So now we have nine equally likely arrangements after the second shuffle. That is:
B A C A B C B C A A B C B A C C B A A C B B C A C A B
The final step is to randomly move the final element to a new random position and this has three possibilities.
The third ement is moved to the first element:
B A C > C A B A B C > C B A B C A > A C B A B C > C B A B A C > C A B C B A > A B C A C B > B C A B C A > A C B C A B > B A C
The third element is moved to the second:
B A C > B C A A B C > A C B B C A > B A C A B C > A C B B A C > B C A C B A > C A B A C B > A B C B C A > B A C C A B > C B A
And finally the third element is moved to the third position:
B A C > B A C A B C > A B C B C A > B C A A B C > A B C B A C > B A C C B A > C B A A C B > A C B B C A > B C A C A B > C A B
This completes the scan through the array and we have now listed each of the 27 possible outcomes and all are equally likely.
Gathering the results together gives:
CAB CBA ACB CBA CAB ABC BCA ACB BAC
BCA ACB BAC ACB BCA CAB ABC BAC CBA
BAC ABC BCA ABC BAC CBA ACB BCA CAB
Sorting them into order reveals the problem:
ABC ABC ABC ABC 4 ACB ACB ACB ACB ACB 5 BAC BAC BAC BAC BAC 5 BCA BCA BCA BCA BCA 5 CAB CAB CAB CAB 4 CBA CBA CBA CBA 4
where the numbers at the end of the list shows the number of repeats.
If the shuffle were random then each three letter order would occur the same number of times but you can see that ACB, BAC and BCA are produced more often. If you were using the shuffle to play cards say and you knew the starting order of the deck this would allow you to bias your bets in favour of the most likely arrangements.
The problem gets worse in the sense that the departure from equal frequencies increases as the number of items being shuffled increases.
The fact that there are only 6 combinations of three things and yet the shuffle produces 27 arrangements should give you a clue that something is wrong. A good shuffle should always produce a multiple of n! arrangements and 27 is not a multiple of 6.
The Knuth Fisher Yates Shuffle
So how do you perform a shuffle?
The question is answered by the Knuth shuffle (also known as the FisherYates) shuffle. This can be derived in a number of ways but it simply avoids producing more arrangements than there are of n things.
It does this by making sure that each element is only considered for a random swap once. In other words as the array is scanned the element under consideration is only swapped with elements that haven't been considered so far.
That is
for (int i = 0; i < data.Length; i++) { swap(ref data[i], ref data[i+R.Next(data.Lengthi)]); }
Notice that in this case the random number ranges from i to the number of elements in the array. That is:
i+R.Next(data.Lengthi)
is a random number in the range i to data.Length.
If you write out the steps of this algorithm you discover that on first iteration you get the same result as the earlier shuffle:
no change A B C swap with B B A C swap with C C B A
But on the second iterations the second element can only swap with itself or the third element:
A B C > A B C B A C > B A C C B A > C B A
A B C > A C B B A C > B C A C B A > C A B
And at the third iteration the final element can only swap with itself and so there is no change  for efficiency it would be better to remove this step from the loop.
This gives as the final set of arrangements
ABC BAC CBA ACB BCA CAB
which is just one of each of the possible arrangements of thee things so it is a fair shuffle.
What is surprising about this result is that the difference between the two algorithms is so slight. The difference also seems to be harmless  a few more random swaps. Indeed they almost seem beneficial surely
"the more you shuffle the better"
is so obvious it cannot be false .... but it is.
Always use the Knuth Fisher Yates algorithm, or at least something that is provably random, to shuffle. No matter what your algorithm is it has to be possible to produce the same number of arrangments of n object and so the total number of arrangments the shuffle involves has to be a multiple of n!
A Shortage Of Random Numbers!
Although the purpose of this article isn't to show how to write a casinoquality shuffle algorithm, there is a really interesting problem lurking in all shuffles based on using a random number generator if the number of objects being shuffled is large enough.
Ricky Seltzer emailed us with a simple message
2^{64} < 52!
If you consider using a good algorithm like Knuth FisherYates to shuffle a deck of 52 cards then in principle every arrangement of the deck, i.e. 52! sequences, should occur equally often  but wait! The random number generator is usually only based on 64bit arithmetic which means it repeats at most after "only" 2^{64}, which means that it can't generate more than this number of unique sequences and as 2^{64} << 52! this approach is doomed to fail.
That is, the Knuth FisherYates shuffle will miss out a lot of arrangements of the deck and will not produce a casino quality shuffle because of the limitations of the random number generator in use.
One possible approach is to reseed the generator at each shuffle, but this isn't easy if you have to keep track of the seed. A much better solution would be to use a cryptographicquality random number generator with a much larger period.
This all goes to emphasize the fact that computergenerated random numbers are really pseudo random numbers and have additional properties that you need to keep in mind.
Once again randomness is a tough and subtle subject.
